Display Unit Operating System Usable Charts Presentation Modes ARPA targets Voyage Calculation Route Navigation Monitoring Other Functions FEA-2807: MU-231CE, 23.1" color LCD, UXGA (1600 x 1200 pixels) IHO/S-57 ed3 vector chart, ARCS raster chart, C-MAP CM93 ed3. C-MAP CM-ENC True/Relative Motion Noth-up, True/Relative Motion Course-up Relative Motion Route-up Planned route, Monitoring route Range, Bearing, Speed, Course, CPA and TCPA EBL, VRM, Parallel index line, Cursor position, Navigation and pilot data notebook Route: more than 100 routes The following data can be calculated Range/Bearing to destination, TTG, ETA, Fuel consumption Off track, Waypoint, Arrival, Grounding, Depth Off track, Channel limit, Waypoint approach, Depth Night/day presentation colors, ARPA target display, Radar overlay User chart function, Position optimization, MOB, Log book, Pilot data function, Track control system (TCS)* * Please contact the local dealers in your area for details Radar signal Echo Sounder Water temp Indicator Current Indicator Ethernet 100 Base-TX or RAW Video Relay output Power Supply Display Unit: Processor Unit Equipment List Trackball Control Unit RCU-015 (Specify when ordering) 1 unit 3. Processor Unit EC-1000C 1 unit 5. Power Supply Cable for Processor Unit, 1.5 m 1 pc 6. Power Supply Cable for Display Unit, 1.5 m 1 pc 7. DVI Cable between Display Unit and Processor Unit, 5 m 1 pc 8. Cable between Control Unit and Processor Unit, 10 m 1 pc 10. Standard Spare Parts and Installation Materials 1 set 2. B Adapter EC-1020 for equipment with analog interface 3. Remote Control Unit RCU-016 4. Cable between Control Unit and Remote Control Unit 03S9610, 1.5/10/20/30 m 6. Radar Overlay Kit for FAR-21x5 series and FAR-28x5 series 7. Video Card for Conning Display Unit 8. Cable between Control Unit and Processor Unit, 20/30 m 9. DVI Cable between Display Unit and Processor Unit, 10 m 12. USB-Parallel Printer Cable for PP-510 16. Pedestal slim/standard Type INTERCONNECTION DIAGRAM Control Unit Shipyard Supply Display Unit Processor Unit Remote Control Unit Conning Monitor Track Pilot * Route Backup Echo Sounder Engine Control Water Temp Indicator With 18 portsj* - X? -1 Analog Sensors "Please contact the local dealers in your area for details Display Unit Processor Unit Control Head Trackball Control Unit Remote Control Unit All brand and product names are registered trademarks, trademarks or service marks of their respective holders. SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Nishinomiya, Hyogo, Japan Bordeaux-Mérignac, France Madrid, Spain Hvidovre, Denmark Alesund, Norway Vàstra Frölunda, Sweden Espoo, Finland Gdynia, Poland FURUNO DEUTSCHLAND GmbH Rellingen, Germany St. Petersburg, Russian Federation Piraeus, Greece Electronic Chart Display and Information System

Obtain critical navigation information for safe and efficient travels (Electronic Chart Display and Information System), which have been designed to fully comply with the latest The electronic chart is compatible with ENC (S57 Edition 3) charts, C-Map CM93 ed3, C-MAP CM-ENC and ARCS charts (RASTER CHARTS). Where the ENC chart is not available, the ARCS chart is used instead. Instant conversion is assured, as both chart databases are stored huge navigational data, user actions and performance of The FEA-2107/2807 can be interfaced with up to four sets of radar/ARPA FAR-21x7/28x7 by using of 100...

► The electronic chart can be overlaid with a variety of navigation data such as Radar echo images, ship's position, heading, speed and others to facilitate safe and efficient navigation. Compatible with ENC (S-57 Edition 3) charts, ARCS charts, C-MAP CM93 ed3 and C-MAP CM-ENC ► Complies with the following IMO and IEC regulations: ► Flexible expandability allows the ECDIS to be networked with radar/ARPA, positioning equipment, autopilot and others to consolidate the navigation system When connected to an optional AIS transponder, targets information in its storage buffer, and displays up to 200...

Navigate safely and efficiently with the ECDIS route planning and monitoring Radar overlay Radar echo image overlay is optionally available in the FEA-2107/2807. This function gives the exact match in scale and presentation of the chart and radar echo image. This greatly helps the operator's observation and enhances operators' decision-making process. Radar overlay dialog box Operators can have controls for adjustment of the radar image - gain, sea clutter, rain clutter, echo trail, interference rejector, echo stretch and noise rejector. Radar Outlay 3( urce Conning display A variety of navigation...
